Info fra Produsent
The DTX532K features the DTX-PAD snare, plus real hi-hat and 3-zone cymbal pads that allow true drum playing techniques to be developed.
The DTX-PAD snare has the proper response for developing your technique, and the real hi-hat trigger and stand lets you position the kit to match your ideal setup. The ride and crash feature cup, bow and edge voices and are “mute-able” and “choke-able”. The DTX502 module includes 691 high-quality sounds and offers drum training functions, practice songs, and easy MIDI recording. The USB port allows control over VSTi software and lets you import custom wave files.
Module: DTX502
Snare : XP80
Tom: TP70 x 2
Floor Tom: TP70
Bass Drum : KP65
Hi-Hat : RHH135 + HS650A
Crash Cymbal: PCY135
Ride Cymbal : PCY135
Rack : RS502
Spesifikasjoner
Configuration
| Trigger Module | DTX502 | |
|---|---|---|
| Rack System | RS502 | |
| Pad Set | DTP532 | |
Size/Weight (Trigger Module)
| Dimensions | Width | 251 mm |
|---|---|---|
| Height | 130 mm | |
| Depth | 48 mm | |
| Weight | Weight | 610 g |
Tone generator
| Maximum Polyphony | 32 notes | |
|---|---|---|
| Voices | Drum and percussion: 691,Melodies: 128 | |
| Effects | Reverb: 9, Master EQ: 2 bands | |
| Drum kits | Preset: 50 User: 50 (Total memory capacity of 1MB.) | |
Sequencer
| Note Capacity | Approx. 104,000 Notes (Total memory capacity of 1MB.) | |
|---|---|---|
| Note Resolution | 96 ppq (parts per quarter note) | |
| Song recording type | Real-time replace | |
| Song tracks | 1 track | |
| Songs | Demo: 1, Practice: 37, Pad: 22, User: 40 | |
| Sequence formats | Proprietary, SMF format 0/1 | |
Click
| Tempo | 30 to 300 BPM, Tap Tempo supported. | |
|---|---|---|
| Beat | 1/4 to 16/4, 1/8 to 16/8, and 1/16 to 16/16 | |
| Timing | Accent, Quarter note, Eighth note, Sixteenth note, Triplet | |
| Training Functions | Groove Check, Rhythm Gate, Measure Break, Tempo Up/Down, Change Up, Pad Gate, Part Mute, Fast Blast | |
Other
| Connectors | OUTPUT [L/MONO] (Standard mono phone), OUTPUT [R] (Standard mono phone), Trigger inputs 1, 5, 6, 9 (Standard stereo phone, L: Trigger, R: Rim switch), Trigger inputs 2, 3, 4, 7 (Standard stereo phone, L: Trigger, R: Trigger), HI-HAT CONTROL (Standard stereo phone), AUX IN (Stereo Mini), PHONES (Standard stereo phone), USB TO HOST | |
|---|---|---|
| Accessories | Power adaptor (PA-130), Module holder, Module holder fastening screws x2, Owner’s Manual | |
Audio Import
| Samples | 20 waves (maximum) | |
|---|---|---|
| Sample Data Bits | 16 bits | |
| Sampling Time * Mono/Stereo | 44.1kHz: 12 sec (mono) | |
| Sample formats | WAV, AIFF | |
