Yamaha Stagepas 100 Portabelt PA-system

Name: Yamaha Stagepas 100 Portabelt PA-system
Brand: Yamaha
SKU: CSTGPAS100
Price: 4990.00 NOK
Availability: PreOrder

kr 4 990,- (ink. mva)

Yamaha sitt STAGEPAS 100 er et kompakt PA-system med stor lyd.

Det er enkelt å både sette opp og bruke noe som gjør det perfekt til mindre konserter.

Bestillingsvare

Ikke på lager, kontakt oss for bestilling og leveringstid.

FRAKTPRISER FRA 99,-

(Gjelder ikke varer over 35 kg)

Varenummer: CSTGPAS100 Kategorier: Aktiv høyttaler, Bluetooth høyttaler, PA-Pakke

Beskrivelse

EXPAND YOUR RANGE, EXTEND YOUR REACH

The STAGEPAS 100 portable PA system strikes a perfect balance between high-quality sound and ultimate portability that will allow you to turn virtually any location into your own intimate live stage. Coming in two versions, one with a battery and one without, the lightweight yet durable design, effort-less operation, and astonishing sound of the STAGEPAS 100 will help you reach your audience with the full expression of your performance.

Compact design. Big sound.

Far more than just a speaker that amplifies your mic or instrument inputs, the diminutive STAGEPAS 100 delivers impressive sonic performance by leveraging some of the same technologies used in our high-end professional products. A powerful, high-quality coaxial compression driver combined with Yamaha’s FIR-X filters for the HF and LF crossover deliver sound pressure, precise phase response, and a natural dispersion that will ensure every nuance of your performance is conveyed loud and clear to your audience.

Start the show in seconds

With an unrivaled ease of operation and a setup requiring mere seconds, the STAGEPAS 100 will have you sounding great and performing in an instant. Just turn the power on, connect a micro-phone and your instrument, turn the volume up, and you’re ready to go. The master EQ is right on the front panel making it easy to dial in your sound or adjust settings on the fly.

“A PA in the palm of your hand”

With all the essentials for a compact PA packed into a durable cabinet weighing just 5 kg, the STAGEPAS 100 takes portability to a whole new level. Having a personal live stage you can easily carry in one hand makes it possible to set up and play literally anywhere, anytime.

6 Hours of non-stop performance

The STAGEPAS 100BTR is compatible with large-capacity lithium-ion batteries capable of up to 6 hours of continuous operation, delivering reliable performance in environments where there is no power source available.

Multipoint Bluetooth® connectivity

The STAGEPAS 100 also comes equipped with multipoint supported Bluetooth functionality adding even more convenience to your set up and operation with wireless connection for music/ audio playback using smartphones and tablets.

The right direction

Easily control your coverage area with the carrying handle that doubles as a stand when the unit is placed on the floor. The attachment screws can be adjusted to change the angle of inclination to direct your sound exactly where it needs to go.

Mounting possibilities

The handle of the STAGEPAS 100 also features a 3/8″ diameter screw hole that enable mounting on a microphone stand for more versatile sound dispersion options.

Whenever. Wherever.

The dedicated BAG-STP100 carrying bag features internal pockets for storing adapters, cables etc., as well as a padded shoulder strap for safe and easy transport to any location.

Spesifikasjoner

		STAGEPAS 100BTR	STAGEPAS 100
Outline
Type		2-way Bi-amp Powered Speaker with mixer	2-way Bi-amp Powered Speaker with mixer
I/O	Innganger	INPUT 1: Combo (mic/line), INPUT 2: Combo (mic/line), INPUT 3: Stereo Mini x1 (line)	INPUT 1: Combo (mic/line), INPUT 2: Combo (mic/line), INPUT 3: Stereo Mini x1 (line)
	Utganger	OUTPUT: XLR3-32 (INPUT 1-3 mix)	OUTPUT: XLR3-32 (INPUT 1-3 mix)
	Bluetooth	Ver.5.0, A2DP (SBC, AAC), Class 1	Ver.5.0, A2DP (SBC, AAC), Class 1
Mixing capability	Mixing channels	3	3
	Input channel functions	Hi-Z: CH2	Hi-Z: CH2
	Output channel functions	2 Band EQ	2 Band EQ
General specifications
Speaker type		Coaxcial speaker with compression driver	Coaxcial speaker with compression driver
Frequency range (-10dB)		70 Hz – 20 kHz	70 Hz – 20 kHz
Coverage area		H90ﾟ x V90ﾟ	H90ﾟ x V90ﾟ
Crossover		1.8 kHz (FIR-X)	1.8 kHz (FIR-X)
Maximum output level (1m; on axis)		120 dB SPL *1	120 dB SPL *1
Components	LF	6.5" Cone, 1.7" voice coil	6.5" Cone, 1.7" voice coil
Components	HF	1" throat compression driver, 1.4" voice coil	1" throat compression driver, 1.4" voice coil
Amplifier class		Class-D	Class-D
Power rating	Dynamic	100 W (LF: 93 W, HF: 7 W)	100 W (LF: 93 W, HF: 7 W)
Cooling		Natural convection (no fan)	Natural convection (no fan)
Power consumption		10 W (Idle), 30 W (1/8 power), 50 W (Rated)	10 W (Idle), 30 W (1/8 power, Rated)
Power requirements		100-240 V 50/60 Hz	100-240 V 50/60 Hz
Battery	Type	Rechargeable Lithium ion battery pack	-
	Capacity	60 Wh	-
	Operating Time	Maximum 6 hours, 1/16 power continuous 5 hours	-
	Charging Time	Approx. 2.5 hours	-
Cabinet material		Plastic (PP)	Plastic (PP)
Handle		Bottom x1 (Rotatable)	Bottom x1 (Rotatable)
Flying and mounting hardware		1 × 3/8", depth 12 mm (center of handle)	1 × 3/8", depth 12 mm (center of handle)
Mål (B x H x D)		239 x 310 x 215 mm (9.5" x 12.3" x 8.5"), with handle	239 x 310 x 215 mm (9.5" x 12.3" x 8.5"), with handle
Vekt		5.5 kg (12.1 lbs), without AC adaptor	5.2 kg (11.5 lbs), without AC adaptor
Accessories		Power cord x 1, AC adaptor (PA-500) x 1	Power cord x 1, AC adaptor (PA-500) x 1
Options		Carrying bag: BAG-STP100	Carrying bag: BAG-STP100

*1: Measured peak SPL with pink noise @1m.
