Control Interface
|
|
Keyboard
|
Number of Keys
|
88 |
73 (E1-E7) |
|
Type
|
NW-GH (Natural Wood Graded Hammer) keyboard: synthetic ebony and ivory keytops |
BHS (Balanced Hammer Standard) keyboard: matte black keytops |
|
Voices
|
|
Tone Generation
|
Tone Generating Technology
|
AWM2 |
AWM2 |
|
Polyphony
|
Number of Polyphony (Max.)
|
128 |
128 |
|
Preset
|
Number of Voices
|
57 (Piano: 10 / E. Piano: 14 / Sub: 33) |
57 (Piano: 10 / E. Piano: 14 / Sub: 33) |
|
Effects
|
|
Types
|
Delay
|
2 types (Analog, Digital) |
2 types (Analog, Digital) |
|
Reverb
|
1 type (Hall) |
1 type (Hall) |
|
Master EQ
|
3 bands (with sweepable MID) |
3 bands (with sweepable MID) |
|
Insertion Effect
|
Piano: 2 systems (1: Damper Resonance / 2: Compressor, Distortion, Drive, Chorus), E. Piano: 3 systems (1: Drive / 2: Auto Pan, Tremolo, Ring Modulator, Touch Wah, Pedal Wah, Compressor / 3: Chorus1, Chorus2, Flanger, Phaser1, Phaser2, Phaser3), Sub: 1 system (Chorus/Flanger, Rotary Speaker, Tremolo, Distortion) |
Piano: 2 systems (1: Damper Resonance / 2: Compressor, Distortion, Drive, Chorus), E. Piano: 3 systems (1: Drive / 2: Auto Pan, Tremolo, Ring Modulator, Touch Wah, Pedal Wah, Compressor / 3: Chorus1, Chorus2, Flanger, Phaser1, Phaser2, Phaser3), Sub: 1 system (Chorus/Flanger, Rotary Speaker, Tremolo, Distortion) |
|
Connectivity
|
|
Connectors
|
Linje Ut
|
OUTPUT [L/MONO]/[R] (6.3 mm, standard phone jacks, UNBALANCED), OUTPUT [L]/[R] (XLR jacks, BALANCED) |
OUTPUT [L/MONO]/[R] (6.3 mm, standard phone jacks, UNBALANCED), OUTPUT [L]/[R] (XLR jacks, BALANCED) |
|
Headphones
|
[PHONES] (6.3 mm, standard stereo phone jack) |
[PHONES] (6.3 mm, standard stereo phone jack) |
|
Foot Controller
|
FOOT CONTROLLER [1]/[2], FOOT SWITCH [SUSTAIN]/[ASSIGNABLE] |
FOOT CONTROLLER [1]/[2], FOOT SWITCH [SUSTAIN]/[ASSIGNABLE] |
|
MIDI
|
MIDI [IN]/[OUT] |
MIDI [IN]/[OUT] |
|
USB
|
USB [TO HOST]/[TO DEVICE] |
USB [TO HOST]/[TO DEVICE] |
|
AUX
|
INPUT [L/MONO]/[R] (6.3 mm, standard phone jacks) |
INPUT [L/MONO]/[R] (6.3 mm, standard phone jacks) |
|
Other
|
|
Connectors
|
[AC IN] |
[AC IN] |
|
Display
|
Full Dot LCD (128 x 64 dots) |
Full Dot LCD (128 x 64 dots) |
|
Additional package contents
|
Owner’s Manual x 1, Power cord x 1, Foot pedal (FC3A) x 1 |
Owner’s Manual x 1, Power cord x 1, Foot pedal (FC3A) x 1 |
|
Size/Weight
|
|
Dimensions
|
Width
|
1,298 mm (51-1/8") |
1,086 mm (42-3/4") |
|
Height
|
141 mm (5-9/16") |
144 mm (5-11/16") |
|
Depth
|
364 mm (14-5/16") |
355 mm (14") |
|
Vekt
|
Vekt
|
18.6 kg (41 lb, 0 oz) |
13.1 kg (28 lb, 14 oz) |
