Size/Weight |
Dimensions |
Width |
1,430 mm [56-5/16"] |
1,461 mm [57-1/2"] Polished finish: 1,467 mm [57-3/4"] |
Height |
932 mm [36-11/16"] (with music rest raised: 1,094 mm [43-1/16"]) |
1,027 mm [40-7/16"] Polished finish: 1,029 mm [40-1/2"] |
Depth |
1,237 mm [48-11/16"] |
494 mm [19-7/16"] Polished finish: 494 mm [19-7/16"] |
Weight |
Weight |
135 kg [297 lb, 10 oz] |
87 kg [191 lb, 13 oz] Polished finish: 90 kg [198 lb, 7 oz] |
Dimensions of Packing Box |
W x H x D |
- |
1,582 mm x 784 mm x 814 mm [62-5/16" x 30-7/8" x 32-1/16"] |
Control Interface |
Keyboard |
Number of Keys |
88 |
88 |
Type |
GrandTouch™ keyboard: wooden keys (white only), synthetic ebony and ivory key tops, escapement |
GrandTouch™ keyboard: wooden keys (white only), synthetic ebony and ivory key tops, escapement |
Touch Sensitivity |
Hard2, Hard1, Medium, Soft1, Soft2, Fixed |
Hard2, Hard1, Medium, Soft1, Soft2, Fixed |
88-key Linear Graded Hammers |
Yes |
Yes |
Counterweight |
Yes |
Yes |
Pedal |
Number of Pedals |
3: Damper (with half-pedal function), Sostenuto, Soft |
3: Damper (with half-pedal function), Sostenuto, Soft |
GrandTouch Pedals |
Yes (with GP Response Damper) |
Yes (with GP Response Damper) |
Assignable Functions |
Sustain (Switch), Sustain (Continuous), Sostenuto, Soft, Pitch Bend Up, Pitch Bend Down, Rotary Speed, Vibe Rotor, Song Play/Pause |
Sustain (Switch), Sustain (Continuous), Sostenuto, Soft, Pitch Bend Up, Pitch Bend Down, Rotary Speed, Vibe Rotor, Song Play/Pause |
Display |
Type |
Full Dots LCD |
Full Dots LCD |
Language |
English, Japanese |
English, Japanese |
Panel |
Type |
Touch sensors |
Touch sensors |
Language |
English |
English |
Cabinet |
Key Cover Style |
Sliding |
Folding |
Music Rest |
Yes |
Yes |
Music Braces |
Yes |
Yes |
Voices |
Tone Generator |
Piano Sound |
Yamaha CFX, Bösendorfer Imperial |
Yamaha CFX, Bösendorfer Imperial |
Binaural Sampling |
Yes (“CFX Grand” and “Bösendorfer” only) |
Yes (“CFX Grand” and “Bösendorfer” only) |
Virtual Resonance Modeling (VRM) |
Yes |
Yes |
Grand Expression Modeling |
Yes |
Yes |
Polyphony |
Number of Polyphony (Max.) |
256 |
256 |
Preset |
Number of Voices |
53 Voices + 480 XG Voices + 14 Drum/SFX Kits |
53 Voices + 480 XG Voices + 14 Drum/SFX Kits |
Compatibility |
XG (GM), GS (for Song playback), GM2 (for Song playback) |
XG (GM), GS (for Song playback), GM2 (for Song playback) |
Effects |
Types |
Reverb |
7 types |
7 types |
Chorus |
3 types |
3 types |
Brilliance |
7 types + User |
7 types + User |
Insertion Effect |
12 types |
12 types |
Intelligent Acoustic Control (IAC) |
Yes |
Yes |
Stereophonic Optimizer |
Yes |
Yes |
Functions |
Dual/Layers |
Yes |
Yes |
Split |
Yes |
Yes |
Duo |
Yes |
Yes |
Songs |
Preset |
Number of Preset Songs |
27 Voice Demo + 50 Classics + 303 Lesson Songs |
27 Voice Demo + 50 Classics + 303 Lesson Songs |
MIDI Recording |
Number of Songs |
250 |
250 |
Number of Tracks |
16 |
16 |
Data Capacity |
Approx. 500 KB/Song (approx. 22,000 notes) |
Approx. 500 KB/Song (approx. 22,000 notes) |
Audio Recording (USB flash drive) |
Recording Time (max.) |
80 minutes/Song |
80 minutes/Song |
Compatible Data Format |
Playback |
SMF (Format 0, Format 1), WAV (44.1 kHz, 16-bit, stereo) |
SMF (Format 0, Format 1), WAV (44.1 kHz, 16-bit, stereo) |
Recording |
SMF (Format 0), WAV (44.1 kHz, 16-bit, stereo) |
SMF (Format 0), WAV (44.1 kHz, 16-bit, stereo) |
Functions |
Piano Room |
Yes |
Yes |
Rhythm |
Number of Rhythms |
20 |
20 |
Overall Controls |
Metronome |
Yes |
Yes |
Tempo Range |
5 – 500 |
5 – 500 |
Transpose |
−12 – 0 – +12 |
−12 – 0 – +12 |
Tuning |
414.8 – 440.0 – 466.8 Hz (approx. 0.2 Hz increments) |
414.8 – 440.0 – 466.8 Hz (approx. 0.2 Hz increments) |
Scale Type |
7 types |
7 types |
USB Audio Interface |
44.1 kHz, 24 bit, stereo |
44.1 kHz, 24 bit, stereo |
Bluetooth |
Audio, MIDI (varies by area) |
Audio, MIDI (varies by area) |
Storage and Connectivity |
Storage |
Internal Memory |
Total maximum size approx. 1.4 MB |
Total maximum size approx. 1.4 MB |
External Drives |
USB flash drive |
USB flash drive |
Connectivity |
Headphones |
Standard stereo phone jack (× 2) |
Standard stereo phone jack (× 2) |
AUX IN |
Stereo mini jack |
Stereo mini jack |
AUX OUT |
Standard phone jack (L/L+R, R) |
Standard phone jack (L/L+R, R) |
USB TO DEVICE |
Type A |
Type A |
USB TO HOST |
Type B |
Type B |
DC IN |
24 V |
24 V |
Amplifiers and Speakers |
Amplifiers |
(45 W + 45 W + 45 W) × 2 |
(45 W + 30 W + 40 W) × 2 |
Speakers |
(16 cm + 8 cm with Waveguide + 2.5 cm (dome) with Waveguide) × 2, Spruce Cone Speaker |
(16 cm with diffuser + 8 cm with diffuser + 2.5 cm (dome) with Bidirectional Horn) × 2, Spruce Cone Speaker |
Power Supply |
AC Adaptor |
PA-500 |
PA-500 |
Power Consumption |
60 W (When using PA-500 AC adaptor) |
55 W (When using PA-500 AC adaptor) |
Auto Power Off |
Yes |
Yes |
Accessories |
Included Accessories |
Owner’s Manual, “50 Classical Music Masterpieces” Music Book, Online Member Product Registration, Bench*, Power cord*/AC adaptor* (PA-500) *Varies by area |
Owner’s Manual, “50 Classical Music Masterpieces” Music Book, Online Member Product Registration, Bench*, Power cord*/AC adaptor* (PA-500) *Varies by area |
Separately Sold Accessories |
Headphones (HPH-150, HPH-100, HPH-50), Pedal unit (FC35), AC adaptor (PA-500), USB wireless LAN adaptor (UD-WL01) |
Headphones (HPH-150, HPH-100, HPH-50), Pedal unit (FC35), AC adaptor (PA-500), USB wireless LAN adaptor (UD-WL01) |
