Aktiv høyttaler som egner seg som fulltone, toppkasse eller «fill-in» høyttaler.
Flyfester for enkel installasjon. Maks lydtrykk (SPL)127dB.
Key Features and Benefits:
· High output SPL and sensitivity
· 1 x 12” high power transducer with 75mm voice coil
· 1 x 3” compression driver
· 90º x 40º coverage pattern
· Built-in power amplifier module
· Master volume control
· XLR input and output connectors
· Input and output connectors
· 120Hz low cut switch
· Computer aided design to optimise frequency and phase response
· Cabinet design for FOH use
· Suitable for use as a main system with or without sub speaker augmentation
· Portable system (stand), or permanent installation (wall, ceiling, under balcony)
· Adjustable flying track on the top and bottom of the speaker
· Arrays with MU12B, MU12Ba, MU18B and MU18Ba high power sub speakers for
extended low frequency, high quality music reproduction
· Powder coated grill with foam backing
· Durable Polyurethane textured base paint
Cabinet Dimension:
System Specifications: |
|
Construction |
15mm Birch Plywood |
Transducers |
1 x 3” HF Compression Driver + 1 x 12” LF |
Crossover |
1.8kHz |
Frequency response(-3dB) |
55Hz- 17KHz |
Rated power |
LF 300W, HF 50W (RMS) |
Amplifier Type |
Class H |
sensitivity(1W@1m) |
97dB |
Maximum SPL (1W @ 1m) |
121dB/127dB (peak) |
Rated Impedance |
8Ω |
Dispersion(H×V) |
90 ° x 40° |
Connector |
2 x NL4 |
Power Supply |
110V/220V |
Dimensions(W×H×D) |
420mm (16.5”) x 420mm (16.5”) x 610mm (24”) |
Packaging Dimensions (W×H×D) |
530mm (20.8”) x 530mm (20.8”) x 730mm (28.7”) |
Net Weight (1 piece/pack) |
29kg (63.8lb) |
Gross Weight(1 piece/pack) |
31kg (68.2lb) |
