Beta Three DS1800 distribusjon
Distribusjon for lydsignal. Passer utmerket til lokaler med flere rom.
Eller der du har behov for å splitte et signal fra 2 til 4 eller 1 til 8. Alle kontakter på balanserte xlr. Du kan også linke flere DS1800 sammen i mono eller stereo.
Product Description:
The DS1800 is a 1U, 2 in 4 out, or 1 in 8 out Distribution Amplifier.
Key Features and Benefits:
- Front Panel
Independent volume control to adjust each channel (concealed controls)
LED indicator for mode selection
LED signal indicators - Rear Panel
2 x Balanced XLR input connectors
8 x Balanced XLR output connectors
2 x XLR link connectors
Mode switch for 2 x 4 or 1 x 8
Specifications |
|
Input Connector |
2 x Balanced XLR |
Input Impedance |
8 x Balanced XLR, 2 x Balanced XLR Link |
Maximum Output Levels |
Balanced 10kΩ |
Max.Output Level |
≥ + 20dB |
Frequency Response (±0.3dB) |
20Hz-20kHz |
THD + N |
<0.008% |
S/N Ratio (A weight) |
>100dB |
Dynamic Range |
≥ 115dB |
Power Consumption |
<8W |
Power Supply |
220V 50Hz |
Dimensions (W x D x H) |
483mm (19”) x 172mm (6.8”) x 45mm (1.8”) |
Net Weight (1 piece/pack) |
2.5kg (5.5lb) |
Gross Weight (1 piece/pack) |
3.5kg (7.7lb) |
